| Machine Type |
Universal / Horizontal / Vertical Milling Machine |
| Applicable Standards |
IS 6893, IS 8614, IS 9474 |
| Machine Construction |
Heavy-Duty Cast Iron Construction |
| Table Size |
1200 × 300 mm to 2000 × 400 mm* |
| Longitudinal Travel (X-Axis) |
700 – 1300 mm* |
| Cross Travel (Y-Axis) |
225 – 500 mm* |
| Vertical Travel (Z-Axis) |
400 – 650 mm* |
| Table Swivel |
±45° (Universal Models) |
| Spindle Taper |
ISO-40 / ISO-50 |
| Spindle Speed |
Approx. 35 – 1800 RPM* |
| Number of Speeds |
Up to 18 |
| Feed Range |
Approx. 16 – 800 mm/min* |
| Spindle Motor |
5.5 – 10 HP* |
| Feed Motor |
3 HP* |
| T-Slots |
3–5 Slots, depending on model |
| Coolant System |
Electric Coolant Pump |
| Operation |
Manual / Power Feed |
| Table Loading Capacity |
Model dependent |
| Drive System |
Geared / Power Feed |
| Application |
Heavy-Duty Industrial Machining |
